可以使用少量高电压，高值电容和整流二极管构建小型无变压器焊接机电路，以下文章介绍了更多内容。这一想法是由TUN先生的要求。
在我早期的帖子中，我们遇到了一个完整的成熟100 AMP SMPS焊接逆变电路for working with reasonably bigger joints and metals.
设计理念
Being an SMPS based design and involving high power specs, the above circuit is complex and may be out of the reach of the new hobbyists.
根据TUN先生的要求，自制小型焊接机电路是大多数新的爱好者和机械工程师都可以寻求解决偶尔的工作台金属焊接工作。
A mini welding machine without using complex circuitry could probably be built using a capacitive power supply as shown in the following diagram:
The idea shown above is an ordinary电容电源电路在它们的值方面包含极端电容器。
Circuit Operation
在输入侧，我们可以看到强大的500UF / 400V电容器，而在输出侧的同时也可以看到类似的额定电容，用于加强电流。
焊接系统中最基本的最基本参数是高电流，从而在所讨论的金属接头上，可以在短路结处形成极高的温度。
通过使用高瓦特变压器或其在第一段中讨论的SMPS版本可以实现这种高电流产生。
变压器可能太笨重和沉重，而SMPS电路对于新人来说太复杂，唯一通过相对更简单的设计实现高电流焊接的方法可能是使用high current capacitive power supply如上所示。
可以预期500UF / 400V电容器可以产生电流突发，高达36放大器@ 220V，并用补充输出滤波电容加强此电流可以进行一些严重的焊接动作。
您可以使用以下两个计算器软件验证上述规范：
所示的按钮使用户能够通过短裤突发实现焊接作业，而不是通过连续电弧，这可能是危险的，并且不建议在焊接操作中使用任何道路。
The input 500uF/400V capacitor looks massive and it might not be readily available in the market, therefore this can be built by using 500 numbers of 1uF/400V PPC capacitors wired in parallel, this could occupy some space, but still the method is easily achievable.
使用非极性电容器
该电容器需要优选地是非极性电容器，然而，由于二极管以串联定位，因此电解质电容器也可以在没有问题的情况下起到目的。
输出侧的第二电容器可以肯定是电解型。
For more current, the values of the caps could be increased to higher limits, that's the only parameter that needs to be focused on.
CAUTION: The mini welding machine circuit explained above is not isolated from mains and has the potentials to kill a person within seconds, therefore extreme caution is advised while handling this equipment in the powered condition.
